Product Details
|
Description |
Specification |
|
Actual Cooling Capacity |
10.21 TR (35.9 kW) |
|
Nominal Rated Capacity |
10.0 TR |
|
Compressor Input Power |
5.75 kW |
|
Pump Power |
0.75 kW |
|
Total Power Input (Chiller only) |
5.75 kW |
|
Compressor Type |
Hermetic Scroll |
|
Compressor Make / Model |
Danfoss |
|
Quantity of Compressors |
1 No. |
|
Refrigerant Circuits |
1 Circuit |
|
Refrigerant |
R–407C /R-410A |
|
Total Heat Rejection |
52 kW |
|
Full Load EER |
11.23 Btu/Wh |
|
Full Load COP |
3.29 W/W |
|
Estimated IPLV (COP) |
3.0 – 3.2 W/W |
|
Estimated IPLV (EER) |
10.5 – 11.0 Btu/Wh |
|
Total Power / TR |
0.57 kW/TR |
|
Altitude |
0 m |
2. CONDENSER DETAILS (WATER COOLED SHELL & TUBE)
|
Description |
Specification |
|
Type |
Shell & Tube – Water Cooled |
|
Entering / Leaving Condenser Water |
30 °C / 35 °C |
|
Condenser Water Flow Rate |
10.5 – 11.0 m³/h |
|
Design Pressure |
150 psig |
|
Fouling Factor |
0.000018 m²·K/W |
|
Tube Material |
Copper (C12200) |
|
Tube OD |
19 mm |
|
Pass Arrangement |
2-Pass |
|
Shell Material |
Carbon Steel (IS 2062) |
|
Water Velocity |
1.0 – 1.2 m/s |
|
Pressure Drop |
0.05 – 0.10 bar |
|
Heat Rejection |
49 – 52 kW |
